Place of Origin: | Foshan, China |
Brand Name: | Bestar Packaging |
Certification: | NBCE |
Model Number: | Bestar liquid packaging machine BSTV-450P |
Minimum Order Quantity: | 1 set |
---|---|
Price: | Bestar Packaging Machine |
Packaging Details: | standard export wooden case |
Delivery Time: | 15-20 working day |
Payment Terms: | T/T, Western Union |
Supply Ability: | 30-50 sets per month |
Voltage & Power: | 220V, 50/60HZ, 3.5KW | Dimension(L*W*H): | 1480x1120x1470mm |
---|---|---|---|
Application: | Water, Milk, Juice, Sauce, Jam, Etc | After-sales Service Provided: | Engineers Available To Service Machinery Overseas,Field Maintenance And Repair Service,Field Installation,Video Technical Support |
Certification: | NBCE | Automatic Grade: | Fully Automatic, Semi-automatic |
Type: | Automatic Packing Machine | Driven Type: | Pneumatic |
Packaging Material: | Plastic, OPP/CPP, OPP/CE, PET/AL/PE, Other Laminated Films Hot Sealable Material | Packaging Type: | Stand-up Pouch, Bags, Film, Foil, Pouch, Pillow Bag/Gusset Bag/Quad Bag |
Measurement: | 100-1500ml | Film Width: | 180-450mm |
Bag Width: | 80-215mm | Bag Length: | Max 300mm |
Film Roll Diameter: | Standard Max.320mm | Film Thickness: | 50-120 Microns |
Warranty: | 1 Year | Function: | Feeding, Sealing, Filling |
Product Name: | Automatic Vertical Liquid Packaging Machine | Packing Speed: | 20-42 Bags/min |
Machine Material: | Stainless Steel | Machine Weight: | 700KGS |
Contact Person: | Rachel He | Mobile/whatsapp: | +86 13794095877 |
Wechat: | Rachelbestar | Skype: | Rachel Bestar |
Email: | Bestarrachel@gmail.com | Website: | Www.verticalpackagingmachinery.com |
Youtube: | Https://www.youtube.com/channel/UC8Mi7vT8rH_tlM0Jp4EATMg/ | Facebook: | Https://www.facebook.com/bestarpackagingrachel |
LinkedIn: | Www.linkedin.com/in/BestarpackagingRachel | Twitter: | Https://twitter.com/BestarRachelHe |
QQ: | 1326935862 |
Liquid pure water pouch automatic packing machine with pump, stainless steel machine
www.bestarpackaging.com
www.verticalpackagingmachinery.com
Bestar packing machine manufacture vertical liquid packing machine, juice VFFS machinery, shampoo packaging equipment, tomato sauce filling machine, seasonings pouch making machine. Applicated for packaging liquid for 100ml-5000ml.
Machines can automatically complete all the process from feeding, weighing, filling and bag-making, date-printing to finished products outputting.
Automatic liquid packing machine, pouch water packing machine
Stainless steel packing machine for drinking water pouch pack, China factory price
Liquid pure water pouch automatic packing machine with pump
Full automatic packing machine for liquid, water pouch, pneumatic with pump
Pure water filling and packing PE bag sachet high speed machine
Pouch water filling and sealing machine automatic measuring 500ml, 1000ml, 2000ml, 5000ml
Liquid packing machine for natural drinking water, mineral freshwater
Bestar liquid packaging machine for pure drinking water packing in pouch
How to pack liquid water sachet by machine automatically
Bestar liquid packing machine pictures and packing samples
1. Bestar Machine Factory price, 100% machine quality guarantee, 100% on-time shipment guarantee.
2. Use the SIEMENS PLC control system and 7-inch color touch screen, the operation is more stable & reliable.
3. Fully automatically complete all the process from feeding, weighing, filling, packaging, sealing, date printing. High performance, packaging beautiful.
4. Servo film transporting system and color sensor, positioning accuracy, high precision digital weighing sensors.
5. Work environment quiet, low noise, saving energy.
6. Each machine give full spare part for free as standard.
7. English and your native language touch screen display, intuitive and simple operation.
8. Suitable for kinds of laminated films which hot sealable material roll film.
9. Material touch parts (Packaging machine, liquid metering pump & tank, Bag former, etc.) are to realize fast disassembly, easy to clean and maintain.
BESTAR liquid packing machine Main Machine Technical Parameters
BESTAR Liquid Main Machine Technical Parameters | |||||
Machine type | BSTV-350P | BSTV-450P | BSTV-550P | BSTV-650P | BSTV-750P |
Film width Max | Max.350mm | Max.450mm | Max.550mm | Max.650mm | Max.750mm |
Film width range | 100-350mm | 180-450mm | 220-550mm | 280-650mm | 320-750mm |
Bag width | 40-165mm | 80-215mm | 100-265mm | 130-315mm | 150-365mm |
Bag length | Max.260mm | Max.300mm | Max.400mm | Max.450mm | Max.500mm |
Film roll diameter | Standard Max.320mm | Standard Max.320mm | Standard Max.320mm | Standard Max.320mm | Standard Max.320mm |
Packaging speed | 20-45bags/min | 20-42bags/min | 20-40bags/min | 15-40bags/min | 10-40bags/min |
Measurement range | 100-800ML | 100-1500ML | 200-2200ML | 500-3000ML | 500-5000ML |
Film thickness | 50-120 microns | 50-120 microns | 50-120 microns | 50-120 microns | 50-120 microns |
Voltage Power | 220V, 50/60Hz, 3KW | 220V, 50/60Hz, 3.5KW | 220V, 50/60Hz, 3.8KW | 220V, 50/60Hz, 4KW | 220V, 50/60Hz, 4.2KW |
Main Machine size (mm) | (L)1121×(W)1035×(H)1200 | (L)1480×(W)1120×(H)1470 | (L)1660×(W)1200×(H)1780 | (L)1470×(W)1290×(H)1950 | (L)1470×(W)1290×(H)1950 |
Machine Weight | 600KG | 700KG | 780KG | 800KG | 850KG |
Measuring form | Liquid Pneumatic Pump Filling | ||||
Packaging material | BOPP/CPP, PET/AL/PE, PET/PE, MCPP/BOPP, etc Laminated films which hot sealable material roll film. | ||||
Bag type | Pillow back sealing, Central sealing bag, Gusset Bag, stand up pouch, continuous bags(bag links), punching, etc. | ||||
Air compressor Suggest | 1. m³/min: minimum 1.0 2. Mpa: 0.5-0.8 3. KW: Min 7.5KW | ||||
Remark | 1. Machine Voltage standard 220V, Single Phase. Could customize for 380V, Three Phases, etc. 2. The sizes mentioned above are for the main machine. |
Various bag types:
Bestar liquid packing machine units include the following parts:
* Liquid Metering Pump: Accuracy up to 99%
* Bestar Main machine: for automatic making bags
Bestar liquid packing machine Following devices are optional:
* Product conveyor
* Gusset bag device
* LDPE film device
* hole punch device (round hole/Euro hole)
* Pneumatic retainer
* Bag links device
* Additional bag former
* Additional tank
* Turn table
* Automatic Check Weigher
* Metal Detector Machine
Bestar Customer high evaluation:
Machine installation in clients factory:
Bestar After-sales Service:
1. With a professional after-sales service team, we can provide you with a satisfied and technical service no matter which country you are in.
2. Detail Manuals /&Videos of machine installation, adjusting, setting, maintenance are available for you.
3. If you need any assistance when using the machine and the videos can not help, our English technician will have video chatting with you to fix your problem online. 24 hours/365 days online technical support service.
4. Bestar engineers & technicians are available to send to your countries for services if you agree to pay the expenditure.
5. The machine will have 1-year warranty for the machine, 2-years warranty for the electric part. During the warranty year if any of the parts broken not by man-made. We will free post to replace the new one to you. The warranty will begin after the machine packaging & ship.
Why choose Bestar:
Bestar Packaging Machine Advantages
• With more than 12 years of expertise and experience of the packaging machine.
• Machine design & system innovation.
• Machine customized flexibility and professionalism.
• Factory price with high quality and high-efficiency machine, value for money.
• We keep stock of electronic components, touch displays, motors, etc. Ready for immediate delivery.
• Provide customized services for special orders according to specifications.
• Long-term customers are happy customers and repeated customers: The goal of our activities is the long-term satisfaction of our customers by the supply of easy-use and reliable equipment.
Our Factory:
Bestar Packaging Machine is a comprehensive vertical machinery & flow pack machine manufacturing company. Our mission is to build simple, robust and user-friendly packaging machines that are customized to meet the needs of our customers. Bestar Packaging Machine has been involved in Research & Development of next-generation food and industrial packaging technologies since 2007. We offer a range of packaging machines and equipment that allow our customers to leverage our research and expertise to drive growth and reduce cost.
As the professional company in the area of self-developing and manufacturing of packaging machinery, we provide valuable customer: Vertical packaging machine, VFFS packaging machine with multi-head weigher, Liquid vertical packaging machine, granular packaging machine, powder packaging machine, Horizontal pillow packaging machine, flow pack machine, packaging material roll film and food metal detector, corollary equipment for packing machine.
Bestar not only provide customer packaging machine but supply clients the full set packaging solution! We have modern workshops, professional R&D team, and advanced machining equipment to meet your demands and ensure your needs within the shortest time.
Bestar packaging machine has the good reputation in the world, have been exported our machine to more than 80 countries, such as USA, Chile, Peru, Bolivia, Colombia, Mexico, Ecuador, Argentina, Australia, Spain, Germany, Vietnam, Egypt, Thailand, Burma, India, Indonesia, Malaysia, Middle East, Algeria, Morocco, Kenya, Tanzania, Uganda, Rwanda, Nigeria, Sri Lanka and so on.
Quality is Bestar culture! We have a good quality with CE Certification, OEM&ODM service and 24 hours online English technical support directly. We are looking for exclusive agents in different countries for expanding the sales channel, you are warmly welcome to contact us. Wish both of us will have a brilliant future!
Our Certification & Business licence:
Packaging & Shipping:
1) Dedusting & Cleaning
2) Lubricate Drive Parts to protect machine
3) Divide Machine Into pallet cases
4) Use waterproof stretch film wrapping each part of the machine
5) Use Fumigation-free splint pallet to pack strong for protect machine
6) Stick Shipping Mark on each Cases as request
FAQ:
Q1: How do I find a Packing machine model suitable for my product?
To provide you the right packing machine, before quoting, please kindly consult us and providing:
A. Your product name & product picture
B. The bag length & width for your bag/sachet/pouch size
C. How many grams for each bag?
D. Your ideal bag shape
Bestar manufacture more than100 kinds of packaging machines, depend on product and bag size and bag weight. In order to recommend the best suitable machine, we need to know the above information. If you just start this business, no bag size, we can help you to find a similar weight bag for your reference.
Q2: How about the delivery time?
All our machines are customized because different clients have different requirements, delivery will be from 15-25 working days after receiving the down payment.
Q3: Can you offer some video or pictures of the packing machine?
Yes, of course. Besides, we can help you to have your product's packaging if you are available to send us some of your product and then record a video for your reference. If a chance, we can take videos online and show you.
Q4: Is that pack many bag size in the same packing machine?
Every packing machine has its range for bag length and bag width, after getting your full details, we will calculate for you and give you an exact packaging solution, to make sure to provide you the suitable machine.
Need more machines details or videos? Please contact our Bestar team directly. Bestar packaging machine team will try the best to support you about the right packing solution. Thank you!
