Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ

Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ

  • Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ
  • Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ
  • Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ
  • Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ
  • Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ
  • Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ
  • Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ
Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ
Product Details:
Place of Origin: Foshan, China
Brand Name: Bestar Packaging
Certification: NB CE
Model Number: Bestar granules packaging machine BSTV-450AZ
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Bestar Packaging Machine
Packaging Details: standard export wooden case
Delivery Time: 15-20 working day
Payment Terms: T/T, Western Union
Supply Ability: 30-50 sets per month
Contact Now
Detailed Product Description
Voltage & Power: 220V, 50/60HZ, 6.5KW Application: Granules, Hardware, Screw, Nail, Bolt, Spring, Nuts, Fastener, Washers, Rivets, Inserts
After-sales Service Provided: Engineers Available To Service Machinery Overseas,Field Maintenance And Repair Service,Field Installation,Video Technical Support Certification: NB CE
Automatic Grade: Fully Automatic, Semi-automatic Type: Automatic Packing Machine
Driven Type: Pneumatic Packaging Material: Plastic, OPP/CPP, OPP/CE, PET/AL/PE, Other Laminated Films Hot Sealable Material
Packaging Type: Stand-up Pouch, Bags, Film, Foil, Pouch, Pillow Bag/Gusset Bag/Quad Bag Film Width: Max 450mm
Bag Width: 80-215mm Bag Length: Max 300mm
Film Roll Diameter: Standard Max 320mm Film Thickness: 50-120 Microns
Warranty: 1 Year Function: Weighing, Filling, Sealing
Product Name: Automatic Weighing Packaging Machine Packing Speed: 20-42 Bags/min
Machine Material: Stainless Steel Machine Weight: 1200KGS
Contact Person: Rachel He Mobile/whatsapp: +86 13794095877
Wechat: Rachelbestar Skype: Rachel Bestar
Email: Bestarrachel@gmail.com E-mail: Rachel@bestarpackaging.com
Website: Www.verticalpackagingmachinery.com Youtube: Youtube.com/@bestarpackagingrachel
Facebook: Https://www.facebook.com/bestarpackagingrachel LinkedIn: Www.linkedin.com/in/BestarpackagingRachel
Twitter: Https://twitter.com/BestarRachelHe QQ: 1326935862

Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable



How to pack Camphor wood balls [Bestar] automatic weighing packaging machine

Bestar packing machine integrate version with 10 heads weigher and labeling machine

Automatic packing machine making PE gusset bag with 14 heads weigher

Bestar automatic packing machine high configuration with Siemens touch screen

Bestar packing machine with weigher for gusset bag 500g granules packaging

Food factory bulk packing machine with weighing scale

High Speed! How to pack snacks 90 bags per minute

How to pack rubber bands wholesales packaging

Rubber rings batch pouch packaging machine

Bestar newest high speed VFFS packing machine stable at 90 bags per minute





www.bestarpackaging.com
www.verticalpackagingmachinery.com



Application:



Bestar packing machinery manufacture multi heads weigher vertical hardware packing machine, 10-heads or 14-heads combination weigher optional, suitable for the grain and granule products such as: taro balls, popcorn, snack, puffed food, rice, sugar, garlic, spaghetti, vermicelli, soybeans, millet, macaroni, wheat, pumpkin seed, lentils, beans, peas, pulses, sesame seed, green grams, nut, peanut, crunchy coated peanuts, cashew nut, coconut, pistachio nuts, nutcracker, white peanut, groundnuts, mix nuts, raisins, dry fruits, biscuit crack, crack chips, granule food, biscuit, crack, chip, nuts, dry fruit, sunflower kernels, dried pet food, almond, corn beans, crispy rice, sweets, apple slice, dumplings, rice balls, hardware, medicines, vegetables, cheese chips, etc.



Machines can automatically complete all the processes from feeding, weighing, filling and bag-making, date-printing to finished products outputting. Optional finished conveyor and turntable available.



Bestar granules packing machine pictures and packing samples

Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ 0Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ 1Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ 2Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ 3Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ 4





Bestar granules packaging Machine electronic components

Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ 5

Bestar granules packing Machine Description:

1. Bestar Machine Factory price, 100% machine quality guarantee, 100% on-time shipment guarantee.

2. Use the SIEMENS PLC control system and 7 inch colorful touch screen, the operation is more stable &reliable.

3. Fully automatically complete all the processes from feeding, weighing, filling, packaging, sealing, date printing. High performance, packaging beautiful.

4. Servo film transporting system and color sensor, positioning accuracy, high precision digital weighing sensors.

5. Work environment quiet, low noise, saving energy.

6. Each machine give full spare part for free as standard.

7. English and your native language touch screen display, intuitive and simple operation.

8. Suitable for kinds of Laminated films which hot sealable material roll film.

9. Packaging style diversified, pillow back sealing, Gusset Bag, quad seal bag, continuous bags, punching, etc.



BESTAR granules packing machine Main Machine Technical Parameters

BESTAR Multiheads Weigher Main Machine Technical Parameters
Machine type BSTV-350AZ BSTV-450AZ BSTV-550AZ BSTV-650AZ BSTV-750AZ
Film width Max Max.350mm Max.450mm Max.550mm Max.650mm Max.750mm
Film width range 100-350mm 180-450mm 220-550mm 280-650mm 320-750mm
Bag width 40-165mm 80-215mm 100-265mm 130-315mm 150-365mm
Bag length Max.260mm Max.300mm Max.400mm Max.450mm Max.500mm
Film roll diameter Standard Max.320mm Standard Max.320mm Standard Max.320mm Standard Max.320mm Standard Max.320mm
Packaging speed 20-45bags/min 20-42bags/min 20-40bags/min 15-40bags/min 10-40bags/min
Measurement range 100-800g 100-1500g 200-2200g 500-3000g 500-5000g
Film thickness 50-120 microns 50-120 microns 50-120 microns 50-120 microns 50-120 microns
Voltage Power 220V, 50/60Hz, 6KW 220V, 50/60Hz, 6.5KW 220V, 50/60Hz, 6.8KW 220V, 50/60Hz, 7KW 220V, 50/60Hz, 7.2KW
Main Machine size (mm) (L)1121×(W)1035×(H)1200 (L)1480×(W)1120×(H)1470 (L)1660×(W)1200×(H)1780 (L)1470×(W)1290×(H)1950 (L)1930×(W)1450×(H)2100
Machine Weight 1000KG 1200KG 1380KG 1500KG 1600KG
Measuring form Multiheads Weigher Weighing
Packaging material BOPP/CPP, PET/AL/PE, PET/PE, MCPP/BOPP, etc Laminated films which hot sealable material roll film.
Bag type Pillow back sealing, Central sealing bag, Gusset Bag, stand up pouch, continuous bags (bag links), punching, etc.
Air compressor Suggest 1. m³/min: minimum 1.0 2. Mpa: 0.5-0.8 3. KW: Min 7.5KW
Remark 1. Machine Voltage standard 220V, Single Phase. Could customize for 380V, Three Phases, etc.
2. The sizes mentioned above are meant for the main machine size.




Various bag types:

Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ 6





Bestar granules packing machine units include the following parts:

* Vibration: For Feeding Material

* Inclined hoist elevator: For Conveying Material

* Multi heads Weigher: For Weighing accuracy 99%

* Bestar Main machine: For automatically making bags



Bestar granules packing machine Following devices are optional:

* Product conveyor
* Gusset bag device
* LDPE film device

* Nitrogen flushing device

* hole punch device (round hole/Euro hole)

* Pneumatic retainer

* Bag links device

* Additional bag former

* Additional auger screws

* Turn table

* Automatic Check Weigher

* Metal Detector Machine



Bestar Customer high evaluation:

Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ 7



Machine installation in clients factory:

Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ 8



Bestar After-sales Service:

1. With a professional after-sales service team, we can provide you with a satisfied and technical service no matter which country you are in.

2. Detail Manuals /&Videos of machine installation, adjusting, setting, maintenance are available for you.

3. If you need any assistance when using the machine and the videos can not help, our English technician will have video chatting with you to fix your problem online. 24 hours/365 days online technical support service.

4. Bestar engineers & technicians are available to send to your countries for services if you agree to pay the expenditure.

5. The machine will have 1-year warranty for the machine, 2-years warranty for the electric part. During the warranty year if any of the parts broken not by man-made. We will free post to replace the new one to you. The warranty will begin after the machine packaging & ship.



Why choose Bestar:

Bestar Packaging Machine Advantages

• With more than 12 years of expertise and experience of the packaging machine.

• Machine design & system innovation.

• Machine customized flexibility and professionalism.

• Factory price with high quality and high-efficiency machine, value for money.

• We keep stock of electronic components, touch displays, motors, etc. Ready for immediate delivery.

• Provide customized services for special orders according to specifications.

• Long-term customers are happy customers and repeated customers: The goal of our activities is the long-term satisfaction of our customers by the supply of easy-use and reliable equipment.



Our Factory:

Bestar Packaging Machine is a comprehensive vertical machinery & flow pack machine manufacturing company. Our mission is to build simple, robust and user-friendly packaging machines that are customized to meet the needs of our customers. Bestar Packaging Machine has been involved in Research & Development of next-generation food and industrial packaging technologies since 2007. We offer a range of packaging machines and equipment that allow our customers to leverage our research and expertise to drive growth and reduce cost.



Bestar not only provide customer packaging machine but supply clients the full set packaging solution! We have modern workshops, professional R&D team, and advanced machining equipment to meet your demands and ensure your needs within the shortest time.



Bestar packaging machine has the good reputation in the world, have been exported our machine to more than 80 countries, such as USA, Chile, Peru, Bolivia, Colombia, Mexico, Ecuador, Argentina, Australia, Spain, Germany, Vietnam, Egypt, Thailand, Burma, India, Indonesia, Malaysia, Middle East, Algeria, Morocco, Kenya, Tanzania, Uganda, Rwanda, Nigeria, Sri Lanka and so on.



Quality is Bestar culture! We have a good quality with CE Certification, OEM&ODM service and 24 hours online English technical support directly. We are looking for exclusive agents in different countries for expanding the sales channel, you are warmly welcome to contact us. Wish both of us will have a brilliant future!



Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ 9

Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ 10

Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ 11



Our Certification & Business licence:

Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ 12



Packaging & Shipping:

Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ 13

1) Dedusting & Cleaning

2) Lubricate Drive Parts to protect machine

3) Divide Machine Into pallet cases

4) Use waterproof stretch film wrapping each part of the machine

5) Use Fumigation-free splint pallet to pack strong for protect machine

6) Stick Shipping Mark on each Cases as request

Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ 14

Bestar Other packaging machines you could options:

Automatic packaging machine with multi-heads weigher, labeling machine, checkweigher, and turntable BSTV-450AZ 15

FAQ:

Q1: How do I find a Packing machine model suitable for my product?

To provide you the right packing machine, before quoting, please kindly consult us and providing:

A. Your product name & product picture

B. The bag length & width for your bag/sachet/pouch size

C. How many grams for each bag?

D. Your ideal bag shape

Bestar manufacture more than100 kinds of packaging machines, depend on product and bag size and bag weight. In order to recommend the best suitable machine, we need to know the above information. If you just start this business, no bag size, we can help you to find a similar weight bag for your reference.



Q2: How about the delivery time?

All our machines are customized because different clients have different requirements, delivery will be from 15-25 working days after receiving the down payment.



Q3: Can you offer some video or pictures of the packing machine?

Yes, of course. Besides, we can help you to have your product's packaging if you are available to send us some of your product and then record a video for your reference. If a chance, we can take videos online and show you.



Q4: Is that pack many bag size in the same packing machine?

Every packing machine has its range for bag length and bag width, after getting your full details, we will calculate for you and give you an exact packaging solution, to make sure to provide you the suitable machine.



Need more machines details or videos? Please contact our Bestar team directly. Bestar packaging machine team will try the best to support you about the right packing solution. Thank you!
